MSI PRO X870E-P WIFI Gaming Desktop Motherboard – AMD X870E Chipset – Socket AM5 – ATX

$98.89

SKU: SKU9ZRBhiPwLl Categories: Computer Memory & Upgrades, Hardware Components, Technology Tag: MSI Brand: MSI

Description
Reviews (0)

Product Description

MSI PRO X870E-P WIFI Gaming Desktop Motherboard – AMD X870E Chipset – Socket AM5 – ATX

Ryzen 7, Ryzen 9 Processor Supported – 256 GB DDR5 SDRAM Maximum RAM – DIMM, UDIMM – 4 x Memory Slots – Gigabit Ethernet – IEEE 802.11 a/b/g/n/ac/ax/be – HDMI – DisplayPort

The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
MSI motherboards are designed with advanced hardware and technology, well-supporting the demanding computing usage of gaming and AI. Moreover, we also introduce AI to MSI Center and BIOS, making everything more effortless than before.
14+2+1 DRPS POWER DESIGN
Unleash and sustain the maximum performance with a flagship VRM design built with a total of 14+2+1 digital power phases. Combining dual power connectors and 60A Smart Power Stage, PRO X870E-P WIFI is ready for the challenge of high-end processors.
Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.
M.2 Shield Frozr
Strengthened M.2 thermal solution helps keep M.2 SSD safe and ensures incredible performance.
Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat.
7W/mK Thermal Pad & Additional Choke Pad
High-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are runnging at high speed.
Enlarged Chipset Heatsink
The enlarged heatsink is designed to reduce dust and noise and capable of maintaining high efficiency of heat dissipation.

Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution – the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
Ryzen 7 processors supported for enhanced, dependable system performance with maximum usability
The DDR5 SDRAM efficiently move data across electric components and provide smooth PC performance
Supported 0 RAID levels provide data reliability and fault tolerance
IEEE 802.11 a/b/g/n/ac/ax/be wireless standard support lets you connect to the internet and have instant access to social media, music, movies, and online games
HDMI interface enables the user to experience a fantastic sound/video quality at the expense of a single cable
DisplayPort host interface lets you conveniently connect multiple monitors to increase productivity
Retrieve a significant number of PCI slots, expansion slots, and peripheral ports that have an enhanced heat dissipation capability with the ATX gaming desktop motherboard
With 4 USB 2.0 ports, transfer several documents without error

Product Specifications

AI-powered

Yes
Audio Channels

7.1
Bluetooth

Yes
Bluetooth Standard

Bluetooth 5.4
Brand Name

MSI
Chipset Manufacturer

AMD
Chipset Model

X870E
Controller Type

Serial ATA/600
Depth

9.6″
DisplayPort

Yes
Error Checking

ECC
Form Factor

ATX
Gigabit Ethernet

Yes
HDMI

Yes
Manufacturer Part Number

X870EPWIFI
Maximum Memory Supported

256 GB
Memory Form Factor

DIMM UDIMM
Memory Speed Supported

8200 MHz 6400 MHz 6000 MHz 5600 MHz
Memory Technology

DDR5 SDRAM
Number of M.2 Interfaces

3
Number of Memory Slots

4
Number of Network (RJ-45) Ports

1
Number of Onboard USB 2.0 Ports

6
Number of PCI Express x1 Slots

1
Number of PCI Express x16 Slots

3
Number of USB 2.0 Ports

4
Onboard Video

CPU Dependent Video
PCI Express Standard

PCI Express 5.0 PCI Express 4.0 PCI Express 3.0
Package Contents

PRO X870E-P WIFI Gaming Desktop Motherboard European Union Regulatory Notice Quick Installation Guide EZ M.2 Clip II Remover 3 x EZ M.2 Clip II EZ Wi-fi Antenna 2 x SATA Cables 1 to 2 EZ Conn-cable (V1)
Processor Socket

Socket AM5
Processor Supported

Ryzen 7 Ryzen 9
Product Model

PRO X870E-P WIFI
Product Name

PRO X870E-P WIFI Gaming Desktop Motherboard
Product Series

PRO
Product Type

Gaming Desktop Motherboard
RAID Levels

0 1 5 10
RAID Supported

Yes
Total Number of Onboard USB Ports

11
Total Number of PCI Express Slots

4
Total Number of USB Ports

10
Total Processor Supported

1
Width

12″
Wireless LAN

Yes
Wireless LAN Standard

IEEE 802.11 a/b/g/n/ac/ax/be
