StarTech VGA Video Extender over CAT5 (ST121 Series), TAA

Extend and distribute a VGA signal to 2 local, and 2 remote displays over Cat5 or better cabling – vga over cat5 extender – vga extender over cat5 – vga over cat 5 extender – vga extender over cat 5 – VGA to Cat5 Extender

The ST121UTP VGA Video Extender over Cat5 allows you to extend your VGA video signal by up to 150 meters (500 feet) and connect up to 4 displays (2 local and 2 remote) from that single source. The ST121UTP is a bundled kit including both a local transmitter and a remote receiver unit, offering a complete solution for scenarios in which remote monitor displays are required.
The local unit features a single VGA input as well as two VGA outputs giving you the ability to view and split your source VGA signal to two independent displays locally. The VGA video signal is then sent over standard 4 pair Category 5 or better UTP cable to the remote unit which also features two additional VGA outputs giving you the freedom to display your VGA source on up to four monitors in total.
The included a mounting bracket for the ST121UTP receiver provides versatile mounting options such as a wall, desk or cabinet.
This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.
More from the Manufacturer
More from the Manufacturer

Consists of 1 Base unit for the local display, and 1 Remote unit for the remote display (up to 2 monitors can be connected at each location)
Extends video cables by up to 500 ft. (150m)
Uses standard Category 5 straight-wired, twisted-pair, network patch cable for economical and reliable data transmission
Included mounting brackets

Product Specifications

Additional Information

Extends the connection distance of VGA displays by up to 500 feet (150 meters) offering flexibility in the placement of your equipment Cat5 extension design allows you to make use of existing Cat 5 or better wiring infrastructure
Brand Name

StarTech.com
Connectivity Technology

Wired
Country of Origin

Taiwan
EU RoHS Declaration URL

https://media.startech.com/cms/pdfs/st121utp_rohs.pdf
End of Life Manual Availability

Yes
Environmental Certification

EU RoHS
Environmental Compliance

Restriction of Hazardous Substances (RoHS) 2 Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Waste Electrical and Electronic Equipment Directive (WEEE)
Environmentally Friendly

Yes
Graphics Modes

SXGA
Limited Warranty

2 Year
Manufacturer Part Number

ST121UTP
Maximum Operating Distance

500 ft
Maximum Video Resolution

1280 x 1024
Media Type Supported

Twisted Pair
Network (RJ-45)

Yes
Number of Input Devices Supported

1
Number of Network (RJ-45) Ports

2
Number of Output Devices Supported

4
Package Contents

VGA Video Extender over CAT5 (ST121 Series) 1 x Mounting Bracket for Receiver (w/ screws) 2 x Sets Rubber Feet 2 x Power Adapter 1 x Instruction Manual
Product Name

VGA Video Extender over CAT5 (ST121 Series)
Product Type

Video Extender Transmitter/Receiver
REACH Declaration URL

https://media.startech.com/cms/pdfs/st121utp_rohs.pdf
REACH free of SVHC

Yes
Receiver Depth

2.40″
Receiver Height

0.80″
Receiver Weight (Approximate)

11.82 oz
Receiver Width

3.30″
Transmitter Depth

2.40″
Transmitter Height

0.80″
Transmitter Weight (Approximate)

11.82 oz
Transmitter Width

3.30″
Twisted Pair Cable Standard

Category 5e
WEEE Statement

https://media.startech.com/cms/pdfs/st121utp_weee.pdf
